Our Product Range
Manufacturing Process
Lost-wax investment casting using silicone and/or ceramic mould technology in a vacuum centrifugal casting process.
Dimensions
max.: Ø 2,000x800 mm, wall thickness min.: 1.2 mm
Unit Weights
max.: 800 kg
Technical Features
- Surface roughness: Ra 6.3 μm
- Strength up to 1,200 N/mm2 (higher upon consultation)
- Temperature resistance up to 1,000 °C
Standards
AMS 4985C, ASTM B367
Near-net-shape production allows components to be supplied ready for installation in some cases, even in the as-cast condition.
Manufacturing Tolerances
PDF Download - Titanium Investment Casting Tolerance Table
(available in German only)
Additional Information
Orders of 1 or more units per shipment are accepted *
Further information
Link to Page "Investment Casting"
* Call-off orders are possible from a batch size of just one piece, depending on the titanium alloy, component weight and geometry.
Call-offs under framework agreements are reliably processed via our distribution warehouse on a just-in-time basis, ensuring a fast and dependable supply of titanium components.
Manufacturing Process
CNC milling, CNC turning, CNC spindle machining, CNC grinding, CNC surface grinding and CNC wire EDM.
Dimensions
max.: Ø 1,300 × 1,000 mm
Unit Weights
Details available on request
Technical Features
- Surface roughness up to Ra 1.2
Manufacturing Tolerances
± 0.01 mm
Other
From individual parts and prototypes to small batches and series production. Framework agreements and weekly scheduled deliveries from our warehouse in Neuötting are possible.
Further information
Link to Page "CNC-Machining"
Manufacturing Process
3D printing using the SLM process
Dimensions
max.: 500 × 500 x 500 mm
Unit Weights
From 0.002 kg up to 440 kg
Technical Features
- Wall thicknesses from 0.7 mm achievable
- 50 µm layer thickness
- Proprietary algorithm for support structures (up to 20% material savings)
Manufacturing Tolerances
± 0.05 mm
Additional Information
- Technical feasibility assessment within 48 hours
- Urgent prototype production within 72 hours plus shipping time
Further information
Link to Page "3D-Printed Parts"
Available Alloys
FT-15 (available on request), GR1-5, GR7, GR9, GR12 (available on request)
Dimensions
- Wall thicknesses:
0.5 mm to 30 mm - Outside diameters:
3 mm to 400 mm - Tube lengths:
100 mm to 12,000 mm
Technical Features
Seamless and welded titanium tubes available on request
Standards
ASTM B338, ASTM B861
Additional Information
Tubes with improved bendability, high strength, and high long-term temperature resistance available on request
Further information
Link to Page "Titanium Tubes"
Product Range
Seamless tubes, welded tubes, square profiles, plates, and other product forms available on request
Dimensions
Details available on request
Unit Weight
Details available on request
Technical Features
- Strength values available on request
- Temperature resistance available on request
Additional Information
Orders of 1 or more units per shipment are accepted *
* Call-off orders are possible from a batch size of just one piece, depending on the titanium alloy, component weight and geometry.
Call-offs under framework agreements are reliably processed via our distribution warehouse on a just-in-time basis, ensuring a fast and dependable supply of titanium components.
Manufacturing Process
Open-die forging, die forging, hot die forging, and near-net-shape forging
Dimensions
Edge dimensions up to 1,500 mm
Unit Weights
up to 2,000 kg
Technical Features
- Strengths up to 1,600 MPa
- Temperature resistance up to 1,000 °C
Manufacturing Tolerances
Available upon request.
Request information on our tolerance table for graphite casting
Additional Information
Orders of 1 or more units per shipment are accepted *
Further information
Link to Page "Graphite Casting"
* Call-off orders are possible from a batch size of just one piece, depending on the titanium alloy, component weight and geometry.
Call-offs under framework agreements are reliably processed via our distribution warehouse on a just-in-time basis, ensuring a fast and dependable supply of titanium components.
Manufacturing Process
Graphite casting and hand moulding processes with core inserts.
Dimensions
max.: Ø 2,500 x 2,000 mm, wall thickness min. 2 mm
Unit Weights
up to 800 kg
Technical Features
- Surface roughness Ra 6.3 µm
- Strength up to 1,200 N/mm2
- Temperature resistance up to 1,000 °C
Standards
AMS 4985C, ASTM B367
Manufacturing Tolerances
Titanium Graphite Casting Tolerance Table
(available in German only)
Additional Information
Orders of 1 or more units per shipment are accepted *
Further information
Link to Page "Forged Components"
* Call-off orders are possible from a batch size of just one piece, depending on the titanium alloy, component weight and geometry.
Call-offs under framework agreements are reliably processed via our distribution warehouse on a just-in-time basis, ensuring a fast and dependable supply of titanium components.
